Weld Star PC40 Dual Voltage Plasma Cutter c/w Air Compressor (Built In)

£1,219.00 ex VAT

Call for further details

In stock

Free Shipping on Welding Supplies £100+ T&C Apply

  • Check Mark Click & Collect Available
  • Check Mark Secure Payments & Easy Returns
weld star


  • The PC40 is a compact, lightweight and portable inverter based plasma cutting machine with a built in air compressor that offers excellent operator flexibility.
  • Advanced, high efficiency plasma systems that offer flexible portability along with smooth and precise cutting characteristics that is ideal when cutting steel, stainless, copper, cast iron as well as aluminium.
  • The Weld Star Infinium plasma range offers the flexibility of switching between the built in compressor or using your own workshop supplied compressed air.
  • Clean cut of 12mm and a severance cut of 16mm. Based on mild steel using workshop compressed air.
  • Auto pilot restart allows for faster restarting of the pilot arc which allows for uninterrupted cutting of grid or perforated type material.
  • Plasma cutting speeds can be up to 1.8 times faster when compared with oxyacetylene cutting.
  • Advanced non HF pilot arc ignition via the supplied plasma cutting torch.
  • The single carry handle offers excellent portability when working or maneuvering on site or in the workshop.
  • User friendly operator control panels.
  • Generator friendly (with built-in AVR).
  • Optional circle cutting guide kit available.
  • 5 year warranty


Input Voltage 110V AC ±15% 50/60Hz 230V AC ±15% 50/60Hz
Ieff (A) 20.4 16
Input Power (kVA) 3.8 5.2
Cutting Current Range (A) 20-30 20-40
No-Load Voltage (V) 400
Duty Cycle @ 40°C 30A@35% 40A@35%
22A@60% 36A@60%
20A@100% 30A@100%
Internal Air External Air Internal Air External Air
Clean Cut (mm) 5 6 10 12
Severance Cut (mm) 6 8 14 16
Min/Max air pressure (external) 5 Bar (75psi) / 6 Bar (87psi)
Minimum gas flow (external air) 4.5CFM 120 Ltr/min
Efficiency (%) 85
Idle State Power (w) 11
Power Factor 0.99
Protection/Insulation Class IP23S/H
Dimensions (LxWxH mm) 610 X 215 X 420
Weight (Kg) 21


Weld Star

Weld Star is a leading brand of welding products, known for their high-quality wires, electrodes, and Infinium welding machines.
